Installation profiles

Oberflex has selected various aluminum profiles specially designed for the shop fitting industry, and offers to do the appropriate machining on the panels.

Metal "H" profiles

Extruded aluminum profiles for a "tongue and groove" type of installation are available in lengths of 3 meters. Finishes: untreated . Other finishes are available upon request.

"U" metal profiles + screwed fasteners

Extruded aluminum profiles for clip-on, detachable or permanent wall installation. Joint options hollow joints, butt joints, joints with separators, etc. Available in lengths of 3 meters. Finishes: untreated, natural anodized or black anodized

Angle profiles

Extruded aluminum profiles are specially designed to optimize the mechanical connection between two cabinet panels installed at 90° angles. Available in lengths of 5 meters. Finish: natural aluminium. Possibility to lacquer.

Angle profiles guarantee a perfect finish and impact protection.

The profiles are compatible with all Oberflex panels. For further information and technical recommendations, please contact the Oberflex Customer Service.
