Panober bonded panels

Prestige d'Oberflex, Textured Wood Collection, and other Oberflex wood collections...

Composition :

Available substrate :

  • Particule board 16 mm or 19 mm, standard E1
  • MDF 16 mm ou 19 mm, standard E1
  • Other on demand

Dimensions (raw edges) :

  • Particule board : 3040 x 1230 mm • 2500 x 1230 mm (except black or white Oak refences - Textured wood collection : 3000 x 1210 mm ou 2500 x 1210 mm)
  • MDF : 3040 x 1200 mm • 2500 x 1200 mm (except black or white Oak refences - Textured wood collection : 3000 x 1200 mm ou 2500 x 1200 mm)
  • Other dimensions : custom sized as per elevation drawings and cutting list.

Thicknesses :

  • 16mm substrate : total thickness = 17,6 to 18,6 mm
  • 19mm substrate : total thickness = 20,6 to 21,6 mm

Balancing :

  • A/A : face 1st choice / counterface 1st choice
  • A/C : face 1er choice / counterface second grade wood veneer
  • A/P : face 1er choice / counterface white decor

Fire ratings :

  • on MDF : M2
  • on particule board : M2
  • Other on demand : Euroclass Bs1d0 or M1



Pure Paper Color

Composition :

Available substrates :

  • Particule board 16 mm or 19 mm, standard E1
  • MDF 16 mm ou 19 mm, standard E1
  • Other on demand

Dimensions (raw edges) :

  • 3040 x 1230 mm - The panels are supplied in oversize and not trimmed to facilitate the patterns matching during application.

Thicknesses :

  • 16 mm substrate : Total thickness = 17,8 mm (17,6 mm for Skin et Figured)
  • 19 mm substrate : Total thickness = 20,8 mm (20,6 mm for Skin et Figured)

Balancing :

  • A/A : face 1st choice / counterface 1st choice
  • A/C : face 1er choice / counterface second grade

Fire ratings :

  • M2
  • Other on demand : IMO, Euroclass Bs1d0 ou M1



Pure Paper Metal

Composition :

Available substrates :

  • Particule board 16 mm or 19 mm, standard E1
  • MDF 16 mm ou 19 mm, standard E1
  • Other on demand

Dimensions (raw edges) :

  • Brushed : 3040 x 1230 mm
  • Mill finish et Glossy : 3040 x 1210 mm

Panels are supplied in oversize and not trimmed to facilitate the patterns matching during application.

Thicknesses :

  • Brushed : 17.8 mm
  • Mill finish et Glossy : 18.2 mm

Balancing :

  • A/A : face 1st choice / counterface 1st choice
  • A/C : face 1er choice / counterface second grade

Fire ratings :

  • M2
  • other on demand : Euroclasse Bs1d0 or M1
Datasheet PANOBER_EN.pdf
